Features & Details

• High Compatibility：The rebar bending machine is widely used in construction engineering for bending or cutting rebar, steel bar, steel rod, screw thread steel, carbon steel, round steel, etc.
• 3.5-4S Ultra-Fast Bending Speed: This electric rebar bender is designed with excellent performance. It helps save valuable person-hours by bending rebar 0.16~0.98inch within 3.5 to 4 seconds. Bending Angle: 0-180°
• 1700W Pure Copper Coil Motor: This hydraulic bending machine features a 1700W pure copper motor, which can run quietly with low noise and significantly improve your working efficiency, reducing unnecessary wear. Besides, a copper motor can extend this electric rebar machine's operating life to a large extent. Voltage: 110V, Frequency: 60 Hz, Amps: 14A, Noise: 92 dB(A).
• Sturdy Machine Body: The electric bender machine adopts a sturdy iron machine body and durable Idler Wheel. Ø78 iron Gyre Idler Wheel and Ø94 Fixed Idler Wheel are stronger and not easy to break. Moreover, it can stand super-hard rebar with strong clamping force, which can help to reduce steel rebar waste.
• Angle Adjustment Knobs: This rebar bending machine has two slide-type angle selectors, which can help you accurately bend any angle from 0-180 degrees. Preset angle locks are designed for repeating the same angle bending. When bending processing, the angle of point 1 must be bigger than point 2. Otherwise, the machine can not operate normally.

Frequently Bought Together

Videos for this product

About this item

Product specification

Item Model Number

RB-25

Product Dimensions

17.7 x 19.7 x 31.1 inches / 450 x 500 x 790 mm

Color

Orange

Net Weight

205.7 lbs / 93.3 kg (including all accessories)

Single Unit Net Weight

200.6 lbs / 91 kg

Rated Power

1700W

Main Materials

Cast Iron, Gear Steel, Module 40 Chrome

Bending/Cutting Diameter

0.16-0.98 ± 0.02 inches / 4-25 ± 0.5 mm

Bending Angle

0°-180°

Description

Bend with Precision – The Ultimate Rebar Bender

If you’re looking for a reliable and efficient tool for bending rebar, the Electric Rebar Bender is your ideal solution. Our hydraulic electric rebar bender can bend solid rebar in just a few seconds, making it especially valuable for construction projects that demand both speed and precision.

The steel rebar bender bends 0.16-0.98inch steel super fast in just 3.5 -4 seconds. Bending Angle: 0-180°. The bending speed depends on the thickness of the rebar and the angle you want to reach.

Adjust the angle you need by moving left or right, and after angle adjustment is set accurately, ensure that the angle setting handle is fixed. When you find some abnormal during the operation, you must press down emergency stopped to close down the machine's operation.

The rebar bending machine features a 100% pure copper core high-power motor with double endurance for high conductivity, low noise operation, high-temperature resistance, and saves energy for a long time.

The foot switch connection at points 1 and 2 enhances convenience. Pressing either the start switch or foot switch will bend the rebar to the set angle. When moving the bender, ensure the 4 bolts are tightened and use the 4 handles to move it together.

See More
